PhotonSilica | PHSI Technologies & Research Pvt. Ltd.

PhotonSilica is R&D FabLab + design house accelerating semiconductor innovation—built in India, for the world. We turn Indian research into domain-qualified silicon for defence & space, automotive, telecom, consumer electronics, data centers, and industrial electronics. No bottlenecks, no Reduced foreign dependency—just rapid, affordable, on-demand prototyping with qualification-first ownership. Fabless today and scaling our R&D FabLab in phases, we carry designs from spec to silicon bring-up and qualification, delivering secure, production-ready chips faster and more cost-effectively.

About Us

PhotonSilica | PHSI Technologies And Research Pvt. Ltd. is a semiconductor R&D design house and FabLab dedicated to turning Indian research into domain-qualified silicon for defence, space, automotive, telecom, consumer, data center, and industrial applications.

We operate as a fabless design house today, building end-to-end capabilities across ASIC/SoC design, verification, and qualification, while scaling a phase-wise R&D FabLab to accelerate on-shore prototyping and testing.

PhotonSilica bridges academia, industry, and government to deliver chips that are not only designed in India, but also qualified for mission-critical use. Our qualification-first approach ensures every design progresses beyond GDSII to EMI/EMC, reliability, and radiation validation through accredited partners.

Our workflow supports:

  • Custom ASIC & SoC design (digital, mixed-signal, RF-adjacent)

  • Reusable IP for secure MCU/crypto, sensor-fusion, PMIC, and radar DSP

  • Prototyping orchestration via multi-foundry MPW routes and local OSAT partners

  • Qualification & compliance for defence, automotive, and industrial standards

Recognitions & programs:
Backed by DPIIT (Startup India), Startup UP, and MSME (Udyam), PhotonSilica is also a beneficiary under the Design-Linked Incentive (DLI) Scheme of the India Semiconductor Mission, Ministry of Electronics & IT, Government of India—aligning with the national vision to strengthen on-shore innovation, manufacturing readiness, and strategic self-reliance.

Registrations

  • CIN:U72100UP2025PTC232742

  • DPIIT Recognized Startup: DIPP222583

  • Startup UP Registered: R/STARTUP/UP/LKO/2025/000040631

  • MSME Registered-:Udyam-UP-08-0037976

  • Importer–Exporter Code (IEC): AAQCP1918B — DGFT, Govt. of India

Tushar Raj— Founder

Deep-tech entrepreneur, Tushar is building the critical infrastructure India needs to lead in advanced semiconductor R&D. He combines technical ambition, financial discipline, and mission-driven execution to develop chips that will power and strengthen national technology sovereignty.

About the Founder

A man in a white shirt and tie speaking at a podium during the SEMICON India 2025 conference, with a large banner behind him displaying the event details and a smaller screen showing a picture of Indian Prime Minister Narendra Modi.
Linkedin

Join the Mission | Career

We’re building the infrastructure for India’s next semiconductor leap — a collaborative R&D FabLab that unites academia, startups, and industry to accelerate chip innovation.
From defence and space to automotive, AI, and photonics, PhotonSilica is creating an open, qualification-driven ecosystem where ideas move from research to silicon — faster, affordable, and on-shore.

Join us as we design, prototype, and qualify the next generation of chips — built in India, for the world.

Write a mail to us at Email: founderOffice@PhotonSilica.in
